Full Color Display
Model #8-80160




12'-1"


10"



6'-1"






Open
Pixel

  Front View   Side View


  Text Capabilities:

6" text per line
(10 lines)
26


Plus graphics (.bmp), animation

s (.gif) & time/temp.


Specifications:
  PIXEL MATRIX:
PIXEL PITCH:
VIEWING ANGLE:
MAXIMUM CONSUMPTION:
NO. OF LED'S PER PIXEL:
LED COLOR:
WEIGHT:
TRANSMISSION OPTIONS:
CONTROLLER:
COMPATIBLE OPERATING SYSTEM'S:
MIN. REQUIRED HARD DRIVE SPACE:
80 x 160
23mm
140 degrees
28 amps
3 (1 red, 1 green, 1 blue)
31.25 Million Colors
750 lbs
Wired or Wireless Ethernet & DSL modem
Embedded PC, DVI link
Windows 95/98/XP/NT
50 MB
Specifications:

Wide Viewing Angle

Open Pixel

Long Life LEDs

Wireless Control

All Aluminum Casing
Energy Efficient

All year Message Scheduling
