LARGE FORMAT DISPLAY
MODEL #10-1680




23'4"
9"


4'8"

Exposed Pixel

  Front View   Side View


  Text Capabilities:

25" text per
line (2 lines)
53" text per
line (1 line)
13-16
10
  Plus graphics (.bmp), animations (.gif) & time/temp.

Specifications:
  PIXEL MATRIX:
PIXEL PITCH:
VIEWING ANGLE:
UTMOST POWER CONSUMPTION:
BRIGHTNESS RATING:
NO. OF LED'S PER PIXEL:
LED COLOR:
WEIGHT:95
TRANSMISSION OPTIONS:
COMPATIBLE OPERATING SYSTEM'S:
MIN. REQUIRED HARD DRIVE SPACE:
16 x 80
89 mm
140 degrees
120 VAC +/- 10% - 60 Hz / 6.5amps
5,000 NITs
25 (exposed pixel)
Amber or Red
910 lbs
Cable, Modem, TCP/IP or Wireless
Windows 95/98/XP/NT
50 MB
Specifications:

Wide Viewing Angle

Exposed Pixel

Long Life LEDs

Wireless Control

All Aluminum Casing
Energy Efficient

All year Message Scheduling
